Interactive Media Control Checkbox Using HTML and CSS (Free Source Code)
The Interactive Media Control Checkbox converts ordinary checkboxes into dynamic UI elements which users prefer to use.
This checkbox serves juniors for coding tasks because it creates media control interfaces from only HTML and CSS elements.
The released code operates as an open-source, featuring good programming design for enhancing web component libraries and UI library development. Let’s explore!
GitHub Source: Interactive Media Control Checkbox
Features
- Smooth Animation: The transition between play and pause icons is seamless and visually appealing.
- Lightweight Code: It uses only HTML and CSS, ensuring fast loading times for your website.
- Responsive Design: The checkbox adapts well to different screen sizes, providing a consistent user experience.
- Customizable Colors: You can easily adjust the color scheme to match your site’s theme or branding.
Technologies Used
- HTML (Hypertext Markup Language)
- CSS (Cascading Style Sheets)
Recommended for You
- Animated Checkbox with Custom Icons
- Modern Skeuomorphic Checkboxes
- Responsive Diamond Checkbox Design
- iOS Checkbox Design for Websites
- Neumorphic Round Checkbox
Procedure to Build Website Checkbox
Addition of this checkbox requires no coding complexity even for users who are new to programming. Set the HTML code in your project files and apply design styles through CSS to your stylesheet. The code functionality depends on semantic labels linked with hidden input elements. Advanced users can modify icons along with colors and animation speeds while utilizing their brand’s specific applications because this function requires zero JavaScript.
HTML
Here is the HTML code for your index.html file:
<!DOCTYPE html>
<!-- Developed by Shokat Javed available at www.jvcodes.com -->
<html lang="en">
<head>
<meta charset="UTF-8">
<meta name="viewport" content="width=device-width, initial-scale=1.0">
<title>Interactive Media Control Checkbox - JV Codes</title>
<link rel="stylesheet" href="style.css">
</head>
<body>
<label class="container">
<input checked="checked" type="checkbox">
<svg viewBox="0 0 384 512" height="1em" xmlns="http://www.w3.org/2000/svg" class="play"><path d="M73 39c-14.8-9.1-33.4-9.4-48.5-.9S0 62.6 0 80V432c0 17.4 9.4 33.4 24.5 41.9s33.7 8.1 48.5-.9L361 297c14.3-8.7 23-24.2 23-41s-8.7-32.2-23-41L73 39z"></path></svg>
<svg viewBox="0 0 320 512" height="1em" xmlns="http://www.w3.org/2000/svg" class="pause"><path d="M48 64C21.5 64 0 85.5 0 112V400c0 26.5 21.5 48 48 48H80c26.5 0 48-21.5 48-48V112c0-26.5-21.5-48-48-48H48zm192 0c-26.5 0-48 21.5-48 48V400c0 26.5 21.5 48 48 48h32c26.5 0 48-21.5 48-48V112c0-26.5-21.5-48-48-48H240z"></path></svg></label>
</body>
</html>
CSS
Here is the complete code for style.css file to style the checkbox:
body {
margin: 0;
display: flex;
justify-content: center;
align-items: center;
min-height: 100vh;
background-color: #383838;
}
/*------ Settings ------*/
.container {
--color: #a5a5b0;
--size: 30px;
display: flex;
justify-content: center;
align-items: center;
position: relative;
cursor: pointer;
font-size: var(--size);
user-select: none;
fill: var(--color);
}
.container .play {
position: absolute;
animation: keyframes-fill .5s;
}
.container .pause {
position: absolute;
display: none;
animation: keyframes-fill .5s;
}
/* ------ On check event ------ */
.container input:checked ~ .play {
display: none;
}
.container input:checked ~ .pause {
display: block;
}
/* ------ Hide the default checkbox ------ */
.container input {
position: absolute;
opacity: 0;
cursor: pointer;
height: 0;
width: 0;
}
/* ------ Animation ------ */
@keyframes keyframes-fill {
0% {
transform: rotate(-180deg) scale(0);
opacity: 0;
}
50% {
transform: rotate(-10deg) scale(1.2);
}
}
Download Source Code
You can get the below code for free for an unlimited time with no copyright limitations. The code base exists for free use enabling users to modify it endlessly for apps dashboards or client projects.
Conclusion
The Interactive Media Control Checkbox modernizes forms, quizzes and media player interfaces making projects more memorable to the user. Your ability to create innovative web components becomes better showcased by adding this feature to your portfolio portfolio marking you unique in your field.
JV Source Codes provided this resource which we are grateful for. You should support JV Codes through website linking. Review some additional UI elements which include forms and galleries together with hero sections. The YouTube channel provides step-by-step guidance for subscribers. Need help? Leave a comment—I will respond!
